RE Series Easy Entry Insulated Ring Terminal：RE1.25, RE2, RE2.3, RE2.5, RE3.5, RE5.5.
| Item | Specification |
|---|---|
| Series | RE Series Easy Entry Insulated Ring Terminal：RE1.25, RE2, RE2.3, RE2.5, RE3.5, RE5.5 |
| Material | High purity red copper tin-plated + Easy entry flame retardant nylon |
| Certification | CE, RoHS, TUV, UL, REACH |
| Rated Voltage | 600V |
| Temperature Range | -40°C ~ 105°C |
| Type | Pre-insulated ring terminal, easy entry type |
| Wire Range | 0.5mm² – 10mm² |
| Feature | Large flared inlet, easy wire insertion, seamless stamping, anti-vibration |
| Application | Electrical cabinet, machinery, automotive, power distribution, grounding wiring |
Product Description
RE Series Easy Entry Insulated Ring Terminal is an upgraded round pre-insulated lug with flared trumpet inlet design, specially optimized for fast and effortless wire insertion.
Made of high-purity red copper with tin-plated surface, seamless integral forming, smooth and burr-free. The enlarged easy-entry insulation opening allows stranded wires to slide in directly without shaping, greatly improving wiring efficiency. Flame retardant nylon sleeve provides excellent insulation, high temperature resistance and anti-aging performance. Round ring hole is suitable for bolt fixing, firm crimping, anti-loose and vibration resistant. Fully certified for global industrial and commercial wiring projects.
Product Features
Easy Entry Flared Design
Trumpet-shaped enlarged inlet, wire inserts smoothly without trimming strands.
Pure Red Copper Tin Plated
High conductivity, low resistance, oxidation and corrosion resistant.
Flame Retardant Nylon Insulation
Heat-resistant, safe insulation, avoid leakage and short circuit.
Seamless Integral Stamping
Smooth edge, no burrs, protect wire core during crimping.
Standard Ring Hole
Perfect for bolt mounting, stable connection, anti-vibration and anti-loosening.
Full Global Certification
CE, RoHS, TUV, UL, REACH compliant for worldwide sales.
Color Coded
Red / Blue / Yellow for quick wire gauge identification.
Application Scope
Electrical control cabinet and distribution box wiring
Mechanical equipment power connection and grounding
Automotive and motorcycle wire harness fixing
Household electrical and electronic equipment wiring
New energy equipment power distribution
Low voltage engineering bolt connection wiring
Easy Entry Flared Design
Trumpet-shaped enlarged inlet, wire inserts smoothly without trimming strands.
Pure Red Copper Tin Plated
High conductivity, low resistance, oxidation and corrosion resistant.
Flame Retardant Nylon Insulation
Heat-resistant, safe insulation, avoid leakage and short circuit.
Seamless Integral Stamping
Smooth edge, no burrs, protect wire core during crimping.
Standard Ring Hole
Perfect for bolt mounting, stable connection, anti-vibration and anti-loosening.
Full Global Certification
CE, RoHS, TUV, UL, REACH compliant for worldwide sales.
Color Coded
Red / Blue / Yellow for quick wire gauge identification.
Application Scope
Electrical control cabinet and distribution box wiring
Mechanical equipment power connection and grounding
Automotive and motorcycle wire harness fixing
Household electrical and electronic equipment wiring
New energy equipment power distribution
Low voltage engineering bolt connection wiring
Installation Diagram & Step Instruction
Step-by-Step Installation Diagram
Standard operation steps for RE easy entry insulated ring terminal. The flared inlet makes wire insertion much faster than conventional terminals.
·Strip proper wire insulation length.
·Insert wire directly into the flared easy-entry end.
·Crimp tightly with professional cold crimping pliers.
·Fix the ring terminal onto bolt and fasten securely.
Precautions
·Choose correct RE model according to wire cross-section and bolt size.
·Do not over-crimp to prevent copper tube and insulation damage.
·Ensure wire fully inserted into the terminal barrel.
·Do not use beyond rated voltage and temperature range.
Step-by-Step Installation Diagram
Standard operation steps for RE easy entry insulated ring terminal. The flared inlet makes wire insertion much faster than conventional terminals.
·Strip proper wire insulation length.
·Insert wire directly into the flared easy-entry end.
·Crimp tightly with professional cold crimping pliers.
·Fix the ring terminal onto bolt and fasten securely.
Precautions
·Choose correct RE model according to wire cross-section and bolt size.
·Do not over-crimp to prevent copper tube and insulation damage.
·Ensure wire fully inserted into the terminal barrel.
·Do not use beyond rated voltage and temperature range.
