260 Series terminal block, 2 wire din rail terminal, WAGO 260-301 replacement, cage clamp feed-through terminal, 1.5mm spring wiring connector
1. Core Structure Difference
- 260-301
- 2 wiring holes: 1 wire in, 1 wire out
- Only realize straight single-circuit connection
- No shunting function, one wire pass through only
- 260-331
- 4 wiring holes: 2 inlet + 2 outlet, all four holes same potential
- Support parallel connection of up to 4 wires for circuit shunting
- Replace small sub-wire box inside control cabinet
2. Same Common Parameters (Both Models)
- Width: unified 8mm
- Wire range: 0.08–1.5mm² / 28–16AWG
- Rated current & voltage: 18A/400V IEC, 10A/300V UL
- Material, temperature resistance, installation way identical
- Full compatible accessories & certifications
- Interchangeable installation position on DIN rail
3. How To Choose Correct Model
- Pick 260-301 if you only need simple one-in-one-out straight wiring for single signal or single power line.
- Pick 260-331 if you need to gather multiple wires to one potential point, for signal distribution and multi-line shunting in compact cabinets.
Comparison Table
| Feature | 260-301 | 260-331 |
|---|---|---|
| Wiring holes | 2 ports (1 in 1 out) | 4 ports (2 in 2 out) |
| Function | Straight through single circuit | Multi-wire parallel shunting |
| Max connected wires | 2 wires total | 4 wires total |
| Usage scene | Basic simple loop | Signal distribution, branch wiring |
| Size & electrical spec | Same 8mm, same rating | Same 8mm, same rating |
