11 pages. Every GS series PCB terminal block in one printable PDF. Pitch options, current ratings, wire-entry angles, ordering codes and complete model lists — the same data our engineers use to answer quotation requests, in a format you can keep on file and share with your team.
What’s Inside the Catalog
- PCB screw terminal blocks — pitch from 3.5 to 10.16 mm (3.5 / 3.81 / 5.0 / 5.08 / 6.35 / 7.5 / 7.62 / 9.5 / 10.0 / 10.16), straight & right-angle, 90° / 135° / 180° wire entry, single / double / triple level
- Barrier terminal blocks — 0.32–5.3 mm² wire range, 7.62–11 mm pitch
- Pluggable terminal blocks — 3.5 to 7.62 mm pitch, plugs and male headers
- Screwless push-in terminals — 2.54 to 7.62 mm pitch
- Transformer terminal blocks — 2×10 mm rail mounting, CQC / UL / CE / RoHS
- Complete ordering-code system — decode pitch, pole count and plating from any model number (e.g. GSP001BW-5.08-06P-11-00A)
Standards: IEC 60998 & UL 1059 · 11 pages · PDF · English
Get the Catalog Now
Enter your business email — the download starts instantly and we'll also send you the PDF link by topic follow-up.
We only use your email for this catalog and any enquiry you send. No newsletters, no spam.
Not Sure Which Series Fits Your Board?
- PCB Terminal Block Types: Complete Selection Guide — compare all five families in one table
- Browse all PCB terminal blocks — individual product pages with specification matrices
- After downloading, simply reply to our follow-up email with your pitch / pole / current requirements or board layout — we’ll return a matched model list and quotation, usually within one business day.
